This projector offers a DICOM Simulation Mode 2 to simulate the results of devices compliant with the Digital Imaging and Communications in Medicine (DICOM) Part 14 standardized display function for display of grayscale images. The DICOM Simulation Mode 2 adjusts the gradation between the minimum and the maximum luminance so gradation is distributed optimally. This feature is optimized for displaying medical images such as X-rays, CAT scans and MRIs, which makes this projector ideal for non-diagnostic purposes such as lectures, academic meetings and in-hospital conferences. This feature is recommended for use in medical schools for training and educational use only.
To optimize color and detail for medical imaging, this projector supports both Blue Base and Clear Base color temperature settings. This feature allows adjustment to achieve the same colors used for DICOM SIM standards, and gives educators the opportunity to adjust color tone according to the type of medical image being shown. In addition to these two settings, presenters have the ability to alter the color temperature between 3 user defined color temperatures for a total of five presets.
Presentations can be enhanced with Picture by Picture split-screen functionality, allowing viewers to see two images side by side from two different viewing sources simultaneously. An advantage of the Picture by Picture Mode is that it also allows both DICOM Simulation images and sRGB Modes to be shown together, meaning a CAT scan, for example, can be simultaneously viewed alongside a live surgery video to bring training to life.
This projector projects bright 5000 lumen*1 images with up to a 2000:1 contrast ratio that helps ensure deep blacks, bright whites and outstanding color. The results are images with crisp depth and dimension, and amazing color accuracy, which is critical to those with discerning needs.
Canon's WUXGA resolution brings bright, true widescreen display of intricately detailed HD video content and still images with outstanding color richness to large-room installations in high resolution WUXGA (1920 x 1200) at a competitive price. Content is projected without compression. Widescreen graphics, text and other visual content from laptops and desktop computers are shown in accurate proportions, just as it appears on most monitor screens.
The exceptional imaging performance of this projector starts with Canon's proprietary AISYS (Aspectual Illumination System) Optical Engine, which utilizes advanced light management technology to maximize the contrast and brightness benefits of the projector's LCOS (Liquid Crystal on Silicon) display panels, which deliver superior reflectivity and durability while accomplishing high luminance. The result is highly detailed, seamless, ultra-sharp image projection in virtually any environment.
Drawing on Canon's advanced optical expertise, this projector utilizes Genuine Canon Optics to project high-quality, virtually distortion-free images.
The lens features a multitude of Canon Lens technologies, such as dual-sided aspherical lens elements as well as Ultra Low Dispersion (UD) lens elements. These elements significantly reduce chromatic aberration, curvilinear distortion, ghosting and flare to create sharp and clear images in a compact projector size.
A short throw ratio of 0.56:1 means that a 100-inch diagonal image can be projected from an approximate distance of only 4 feet away, with virtually no image distortion. This allows for large, accurate images in tight spaces from museums and galleries to simulation and training.
A large vertical (0–75%) and horizontal (±10%) lens shift allows for adjustment of the image with virtually no distortion. Users can be virtually assured that this projector can be optimally positioned to suit their specific environment and needs.
Combined, the short throw ratio and significant lens shift help produce an optimized viewing angle that achieves virtually no distortion right up to the very edge of the image. A deep depth of focus (F2.7) allows images to be rendered highly accurately onto a variety of curved surfaces. Where other projectors may distort or bow at the edges, Canon's optical technology keeps the image periphery extremely straight – exhibiting significantly low TV distortion. This results in beautiful images with smooth edges.
Allows the corners of the image to be independently adjusted to help ensure optimal image reproduction.
360-degree projection*4 allows the projector to be positioned anywhere on the vertical axis. Fan speed can also be adjusted to help optimize results (depending on projector positioning).
Enables users to fine-tune the colors of images based on the color of the projection surface. Adjustments can be made from Normal and Greenboard, as well as additional tuning for projecting onto virtually any other colored surface.
A Picture by Picture feature enables two high-quality images from two digital inputs (via DVI and HDMI) to be projected simultaneously side-by-side within the projected image.
26 test patterns are provided to enable smooth installation and adjustment.
This projector is equipped with a built-in HDBaseT™ receiver facilitating uncompressed HD video, audio and control signals to be transmitted over one single LAN cable with a maximum distance of 100m. This reduces complex wiring schemes used for a typical setup as well as maximizing long cable runs with minimal image quality degradation.
A variety of advanced installation settings provide added customization options for challenging installation areas.
The Edge Blending function enables the user to combine multiple images to create a seamless, extra-wide projection. Advanced functions allow for color blending and black level adjustments to maximize image quality.
The Registration function modifies the registration by electronically correcting color shift due to changes in alignment of each RGB panel position.
The Micro-Digital Image Shift function shifts the image electrically, using the surplus pixels on the LCOS panel.
Fan Mode gives the user the ability to adjust the fan speed to supporting different environmental workspaces.
The Vertical Projection function automatically adjusts fan speeds and other configurations to support vertical installations.
