Stabimatic SP-2KVA Automatic Voltage Regulator Price in Pakistan

Model: SP-2KVA

Availability: Out of stock

Input Voltage: 100 VAC to 140 AVC
Output Voltage: 220V ± 0 to 2 %
Phase: Single-phase
Response time: Within 0.5 sec. against 10% input voltage deviation.
Frequency: 50Hz/60Hz
Efficiency: 90% (input voltage 180V, output voltage 220V and rated load) 50% (input voltage 100V, output voltage 220V and rated load)
Power Factor: Better than 95% (input voltage 180V, output voltage 220V and at rated load)
Ambient Temperature: -5 o C ~ 40 O C
Ambient Humidity: Less than 90% (relative humidity)
Temperature Rise: Less than 75% O C (Input 180V, output voltage 220V)
Cooling System: Convection-cooled (Model 3kVA~10kVA Air blast)
Control System: DC servo-motor
Style: Stand-alone style, model above 3KVA with Wheels
Insulation Resistance: More than 3 M Ohm, at DC 500V
Dielectric Strength: Tested at AC 1500V for 1 min.
Delay Timer : Short 5 sec, Long (5min ± 2) Selectable
Indicators : 4 LED indicators for DELAY, Under Volt, normal & Over Volt
