QuickPick 2.0 AI by Recorder (Number of Channels): 2 channels
Perimeter Protection
Face Attributes: 6 attributes
Face Detection Performance of AI by Recorder (Number of Channels): 2 channels (up to 8 face images/s each channel)
Face Recognition
Face Database Capacity: Up to 10 face databases with 10,000 images.
Face Recognition Performance of AI by Recorder (Number of Channels): 2 channels
SMD Plus
SMD Plus by Recorder: 8 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change
SMD Plus by Camera: 12 channels
AI Video Quality Analytics
AI Video Quality Analytics by Recorder: 8 channels: Supports detecting brightness levels, color cast, defocus, overexposure, contrast levels, black and white
Scene Changing
Scene Changing by Recorder: 1 channel
Irregular Black Block Masking
Irregular Black Block Masking by Recorder: 1 channel
Audio and Video
Analog Camera Input: 8 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect
IP Camera Input: Up to 12 channels of IPC access, 4 IP channels by default +8 channels (analog channels are converted to IP channels), incoming bandwidth: 64 Mbps, recording bandwidth: 64 Mbps and outgoing bandwidth: 64 Mbps, *After IP extension is enabled, Video Quality Analytics, Scene Changing, Face Recognition, Face Detection, SMD, Perimeter Protection and QuickPick 2.0 cannot be used.
Encoding Capacity: Encode Enhancement disabled： Main stream: Channels 1-2 5M-N@(1 fps–25 fps), others 5M-N@(1 fps–12 fps); Channels 1-2 4M-N/1080p@(1 fps–25/30 fps), others 4M-N/1080p@(1 fps–15 fps); 1080N/720p/960H/D1/CIF@(1 fps–25/30 fps); Sub stream: D1/CIF@(1 fps–15 fps); Encode Enhancement enabled： Main stream: Channels 1-4 5M-N@(1 fps–20 fps), others 5M-N@(1 fps-12 fps); (4 channels can be transformed to 5MP@6 fps), Channels 1-4 4M-N/1080p@(1 fps–25 fps), others 4M-N@(1 fps–15 fps)/1080p@(1 fps–12 fps); 1080N/720p/960H/D1/CIF@(1 fps–25/30 fps); Sub stream: D1/CIF@(1 fps–15 fps); *When Encode Enhancement is enabled,Video Quality Analytics, Scene Changing, Face Recognition, Face Detection, Perimeter Protection and QuickPick 2.0 cannot be used.
Multi-screen Display: When IP extension mode not enabled: 1/4/8/9, When IP extension mode enabled: 1/4/8/9/16, Third-party Camera Access: Panasonic; Sony; Hanwha; Axis; Arecont; ONVIF
Compression Standard
Video Compression: AI Coding; Smart H.265+; H.265; Smart H.264+; H.264
Audio Compression: G.711a; G.711u; PCM
Network
Network Protocol: HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.)
Record Mode: General; alarm; motion detection; intelligent; POS
Recording Playback: 1/4/9 It changes to 1/4 split when Face or IVS&SMD is selected in AI Mode.
Backup Method: USB device and network
Playback Mode: Instant playback; general playback; event playback; tag playback; smart playback
Alarm
General Alarm: Motion detection; alarm box; HDCVI alarm; camera external alarm; network alarm; PIR alarm
Anomaly Alarm: Error (no disk, disk error, low space, low quota space; network disconnection; IP conflict; MAC conflict); video loss; video tampering; camera offline
Intelligent Alarm: Face detection; face recognition; perimeter protection; SMD Plus
