- Built-in Native Camera Tracking for ClearOne Unite cameras and many 3rd party cameras using RS-232 and Ethernet VISCA over IP.
- 4 Mic/line inputs and 8 mic/line outputs.
- Next-gen Acoustic Echo Cancellation (AEC) on every mic input.
- Support for SIP-based conferencing up to 5 lines and 5 calls based on line configuration.
- Analog Telco interface.
- Built-in USB audio.
- Built-in DARE algorithm for dynamic feedback elimination.
- Reduced foot-print and power consumption.
- C-Link and P-Link enable easy addition of DSPs and peripherals.
- Configure an entire system of C-linked DSPs with CONVERGE CONSOLE AI software.
- Flexible control options include Conference Controller, BYOD dialer apps or 3rd party control modules.
- Noise Cancellation with Adaptive-Ambience.
- Daisy-chain the CONVERGE Pro 2 with the BMA 360, DIALOG 20 USB 2-Channel Wireless Microphone System, and other peripheral devices through P-Link.
Supports SIP, 4 configurable mic/line audio inputs, 8 configurable mic/line audio outputs, built-in USB audio, and a Telco interface for POTS calls.
Applications
- SIP Conferencing
- POTS Conferencing
- Audio Recording
- Pre-recorded Digital Audio
- Audio Networking over a LAN
- Web Conferencing
- UC Audio Conferencing
- Sound Reinforcement
- Bridge Web Conferences
Workspaces
- Conference Rooms
- Training Rooms
- Lecture Halls
- Courtrooms
- Telemedicine Theaters
- Houses of Worship
CAMERA TRACKING
- Supported Cameras: Unite 150, Unite 200, Unite 160, Unite 260 (One Camera per DSP)
- Communication Protocol: VISCA
- Communication options: Serial (RS-232) or Ethernet (VISCA over IP)
MIC/LINE INPUTS & OUTPUTS
- Inputs: Balanced audio inputs, 3.81 mm Orange color Phoenix/Euroblock type male header, Push-on miniterminal block
- Outputs: Balanced audio outputs, 3.81 mm Black color Phoenix/Euroblock type male header, Push-on miniterminal block
- Frequency Response: 20 Hz – 22 kHz @ +4 dBu, +/- 0.5 dBu
- EIN (Equivalent Input Noise): 20 kHz BW, max gain, Rs = 150 Ω, -126 dBu
- THD + N (Total Harmonic Distortion + Noise): 20 Hz – 22 kHz @ +4 dBu, line level, 0.006 %, 20 Hz – 22 kHz @ -56 dBu, mic level, (0.04 %
- Dynamic Range: 20 Hz – 20 kHz @ 0 dB, ) 105 dB Crosstalk (Mic/Line): Channel to Channel, stimulus at 20 dBu to receptor at -56 dBu, 1 kHz, ( -98 dB
- Input Impedance: Balanced (line to ground), 2.2 kΩ, 1 %
- Nominal Input Level: Adjustable -56 dB to 0 dB, 7 dB step coarse gain
- Maximum Input Level: -65 dBu to 20 dBu
- Phantom Power: 48 V, Impedance 6.81 kΩ
- Output Impedance: Balanced (line to ground), 95 Ω, 1 %
- Output Level: 0 dBu (Nominal), 20 dBu (Max), -40 dBu (Selectable)
USB AUDIO
- Port Type: USB-B connector
- Audio: Digital Audio, 2 x 2 bi-directional channels
- Sample Rate: 48 kHz
- Sample Bit Depth: 24-Bit
- Compatible: USB 2.0, USB 3.0
TELEPHONE
- Port Type: RJ-11
- Frequency Response: Mic/Line Input to Telephone Out: 250 Hz – 3.4 kHz , +/- 2 dB, 4 dBu, Telephone In to Mic/Line Out: 250 Hz – 3.4 kHz, +/- 2 dB, -15 dBu
- THD + N: Mic/Line Input to Telephone Out: (0.1 % @ 4 dBu, Telephone In to Mic/Line Out: ( 0.3 % @ -15 dBu
- Dynamic Range: Mic/Line Input to Telephone Out: > 67 dBu, Telephone In to Mic/Line Out: ) 87 dBu, REN: Ringer Equivalent Number 0.2
- Transhybrid Balance: 30 dB (1 kHz, all AC terminations)
SIP
- Port Type: RJ-45, 10/100 Mbps Ethernet Network, Auto Negotiation
- Audio: 5 Lines
- Codec: G.711 uLaw, G.711 ALaw, G.722
ETHERNET
- Port Type: RJ-45, 10/100 Mbps Ethernet Network, Auto Negotiation
- IP address: IPv4 (IPv6 upgradeable through future s/w, f/w upgrade)
AMPLIFIER OUTPUT
- Speaker Output Port: Dual binding posts
- Audio: 2 Channels
- Output Power: 10 W Max, 8 Ω load
- Frequency Response: 20 Hz – 22 kHz @ +10 dBu, +/- 0.5 dBu
- THD + N: 20 Hz – 22 kHz @ +10 dBu, 1W, 0.3 %
- Dynamic Range: 20 Hz – 22 kHz @ 20 dB, ) 102 dB, with 20 kHz digital low pass filter
- Crosstalk: Channel to Channel, stimulus at 20 dBu, 10 W output to receptor 8 Ω load, 20 Hz – 22 kHz, (-70 dB
C-LINK EXPANSION BUS
- Ports Type: RJ-45 (Cat 5e or Cat 6)
- C-Link In & Out: Proprietary Expansion Bus
- Audio: 150 Expansion channels
- Cable: Solid core, factory terminated Cat 5e or 6 cable
- Distance:Up to 80 ’ (24 m)
P-LINK PERIPHERAL BUS
- Ports Type: RJ-45 (Cat 5e or Cat 6)
- P-Link Out: Proprietary Peripheral Bus
- PoE In: PoE 802.3 af Mode B, Midspan, Power on “spare pairs” 4, 5 and 7, 8, Input voltage range: 48 V to 56 V
- Audio: Up to 3 Beamforming Microphone Array 2 units + up to 3 DIALOG 20 Wireless Receiver units + Up to 3 USB Expander units + Up to 3 GPIO Expander units
- Cable: Solid core, factory terminated Cat 5e or 6 cable
- Distance: Up to 200 ’ (60 m)
RS-232
- Port Type: DB9 Female
- Settings: 9600/19200/38400/57600/115200 Baud; Serial Echo; Flow Control
- Support: Serial commands
GPIO
- Port Type: 5.08 mm Green color Phoenix/Euroblock type male header
- Support: Control, Status, Variable Voltage Control
- Power Pin: 5 VDC @ 350 mA Power Source
- Pin 1 to 4: Open Collector Outputs: 40 VDC @ 250 mA, Active Outputs (Source/Sink): 5 VDC @25 mA, Logic Inputs: 40.2 kΩ pull up, Variable Voltage Control Inputs: 5 VDC max
- Ground Pin: GND
USB CONTROL
- Port Type: USB-B connector
- Location: Front Panel
- Compatible: USB 2.0, USB 3.0
LEDs
- Location: Front Panel
- Status LED: Off: Unit still initializing, Blue - Fast Blinking: Stack Syncing in progress, Blue - Slow Blinking: Unit not configured, Blue - Solid: Configured unit, Red - Fast Blinking: Stack Sync error
- Locate LED: Blue - Blinking: Unit “Locate” command received
- Power LED: Blue - Solid: Unit is powered on
LOCATE BUTTON
- Sensor Type: Capacitive Touch Button
- Location: Front Panel
POWER & THERMAL
- Port Type: AC Inlet
- Mains Voltage: 100-240 VAC, 50/60 Hz
- Power Consumption: 50 Watts Typical
- Thermal: 170 BTU/Hr Typical
- Operating Temperature: 14 °F (-10 °C) to 104° F (40 °C) Ambient Temperature
