Compatibility Information
Host Requirements
The host device must support Power Delivery and DisplayPort Alt Mode or USB-C 3.1 (generation 1 or 2).
Supported Operating Systems
macOS 10.12 or later, Windows 8 / 10 / 11
Media Display Information
- When using macOS, content displayed will be mirrored.
- The ability to display on 4 screens simultaneously depends on the capabilities of the laptop’s graphics card.
Maximum resolution when using a DisplayPort 1.4 USB-C laptop
- Single monitor display: 3840x2160@60Hz via the HDMI port or DisplayPort.
- Dual monitor display: 2560x1440@60Hz via 2 HDMI ports, or via the HDMI port and DisplayPort.
- Triple monitor display: 1920x1080@60Hz via the HDMI ports and DisplayPort.
Charging Information
This dock supports up to 85W of charging via the USB-C upstream port on the back of the dock (indicated with a computer icon). The USB-C Power Delivery port (indicated by “PD”) supports 18W fast charging for your phone or tablet. The USB-A 3.0 port on the front supports 7.5W to charge smaller devices like smartwatches or headphones. The two USB-A data ports on the back of the dock do not support charging.
