Grab TP-Link SG5428XMPP Omada 24-Port Gigabit Stackable Lite L3 Managed PoE++ Switch with 4× 10G Slots

By: TP-Link

Model: SG5428XMPP

Sku: RJZA52G7C7

Be the first to review this product

Sign up for price alert

PKR 199,999

& FREE Two-Day Delivery

Availability: In Stock In Stock

New

  • Interface: 24× 10/100/1000 Mbps RJ45 Ports (8× PoE++, 16× PoE+), 4× 1/10 Gbps SFP+ Slots**, USB 2.0 Port, RJ45 Console Port, USB Type-C Console Port, Fan Quantity: 3
  • Power Supply: 100-240 V~ 50/60 Hz, PoE Ports (RJ45): Standard: 802.3af/at/bt compliant, PoE++ Ports: Ports 1~8 (up to 90W per Port), PoE+ Ports: Ports 9~24 (up to 30W per Port), Power Budget: 500W*, Fast PoE, Perpetual PoE
  • Mounting: Rackmountable, Max. Power Consumption: 587.7 W (220V/50Hz) ( with 500 W PD connected @ 25 °C), 615.8 W (110V/60Hz) ( with 500 W PD connected @ 25 °C), Max. Heat Dissipation: 2004.06 BTU/hr (220V/50Hz) ( with 500 W PD connected @ 25 °C), 2099.88 BTU/hr (110V/60Hz) ( with 500 W PD connected @ 25 °C)
  • Switching Capacity: 128 Gbps per Unit, Stacking: Stacking Number: 4, Stacking Port: 10G SFP+ Slot (all uplink ports can be used as stacking ports), Stacking Bandwidth: Up to 80 Gbps (4 stacking ports)
  • Packet Forwarding Rate: 95.23 Mpps, MAC Address Table: 16 K, Packet Buffer Memory: 12 Mbit, Jumbo Frame: 9 KB
  • Quality of Service: Class of Service, 8 Queues of Priority, Port Priority, IEEE 802.1p Priority, DSCP Priority, Queue Min-Bandwidth, Schedule Mode (SP, WRR, SP+WRR), Bandwidth Control, Rate Limit, Storm Control, Voice VLAN, User-Defined OUI, Smoother Performance, Action for Flows, QoS remark (802.1P Remark, DSCP Remark)
  • L3 Features: IP Interfaces: IPv4: Max 128, IPv6: Max 128, Static Routing, IPv4 Max 512, IPv6: Max 128, Host Route Table: Max 1,024 entries, RIP: Version v1/v2, Max 1,796, OSPF: Version v2/v3; v2: Max 1,796, v3: Max 450, Static ARP: 512 static entries, Dynamic ARP: 3,600 dynamic entries, Proxy ARP, DHCP Server: Max 64 IP Pools, Max 1,000 Manual Binding Entries, DHCP Relay: Relayed Interface, Relayed VLAN
  • L2 and L2+ Features: Link Aggregation, Spanning Tree Protocol, Port-based and VLAN-based Loopback Detection, 802.3x Flow Control, ERPS, Mirroring, RSPAN, MAC Address Table, Multicast, IGMP Snooping, MLD Snooping, L2 Multicast Table: Max 2,000, Fast Leave, Multicast VLAN Registration (MVR), Static Multicast Groups, Multicast Filtering
  • Advanced Features: Automatic Device Discovery, Batch Configuration, Batch Firmware Upgrading, Intelligent Network Monitoring, Abnormal Event Warnings, Unified Configuration, Reboot Schedule, ISP Features: 802.3ah Ethernet Link OAM, L2PT (Layer 2 Protocol Tunneling), Device Link Detect Protocol (DLDP), DDM, sFlow
  • VLAN: Max 4K VLAN Group (802.1q VLAN), 802.1Q Tagged VLAN, MAC VLAN Entries: 60, Multicast VLAN, Management VLAN, VLAN VPN (QinQ): Max 256 entries, GVRP, Protocol VLAN: Protocol Template 16, Protocol VLAN 12 entries, Voice VLAN, Private VLAN
  • Security: Port Isolation, CPU-Defend, ARP Inspection (Dynamic ARP Inspection), DoS Defend, IP-MAC-Port Binding, 1,024 Entries, DHCP Snooping, ARP Inspection, IPv4 Source Guard, IPv6-MAC, Port Binding, 1,024 Entries, DHCPv6 Snooping, ND Detection, ND Snooping, IPv6 Source Guard, DHCP Filter, Static/Dynamic Port Security, Up to 64 MAC addresses per port, Broadcast/Multicast/Unknown-unicast Storm Control, kbps/ratio control mode, 802.1X, Port base authentication, Mac base authentication, VLAN Assignment, MAB, Guest VLAN, RADIUS authentication and accountability support, AAA (including TACACS+), Secure web management through HTTPS with SSLv3/TLS 1.2, Secure Command Line Interface (CLI) management with SSHv2, IP/Port/MAC-based access control
  • Omada App: Yes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. Centralized Management: Omada Cloud-Based Controller, Omada Hardware Controller, Omada Software Controller, Cloud Access: Yes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. Zero-Touch Provisioning Yes. Requiring the use of the Omada Cloud-Based Controller.
  • Management Features: Web-based GUI, Command Line Interface (CLI) through console port, telnet, SNMPv1/v2c/v3, Trap/Inform, RMON (1, 2, 3, 9 groups), SDM Template, DHCP/BOOTP Client, 802.1ab LLDP/LLDP-MED, DHCP Auto Install, Dual Image, Dual Configuration, CPU Monitoring, Cable Diagnostics, Password Recovery, SNTP, System Log, IEEE 802.3az Energy Efficient Ethernet (EEE)
  • System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7/8/10/11, MAC OS, NetWare, UNIX or Linux. Environment: Operating Temperature: -5 °C to 45 °C (23 °F to 113 °F), Storage Temperature: -40 °C to 70 ℃ (-40 °F to 158 ℉) Operating Humidity: 10–90% RH non-condensing, Storage Humidity: 5–90% RH non-condensing
Quantity:
  • Add to Wishlist
  • Add to Compare
  • 8× Gigabit 802.3af/at/bt PoE++ ports (Max 90W per port)
  • 16× Gigabit 802.3af/at PoE+ ports (Max 30W per port)
  • 4× 10 Gbps SFP+ slots
  • Up to 500W total PoE budget*
  • Fast PoE and Perpetual PoE
  • Physical stacking up to 4 units for built-in redundancy and performance
  • L3 features: RIP, OSPF, Static Routing, and DHCP Server/Relay
  • Security strategies: ACL, Port Security, DoS Defend, 802.1X
  • ERPS supports rapid protection and recovery in a ring topology
  • Centralized cloud management via the Omada SDN controller
  • Standalone management via web, CLI, SNMP, and RMON

What This Product Does

Omada SG5428XMPP is a dependable entry-level L3 managed PoE++ switch tailored for the access layer, featuring L3 routing, fast 10 Gbps wired speeds, and stacking options. It boasts a 500W PoE budget,* 24× gigabit RJ45 ports (8× PoE++, 16× PoE+), 4× 10 Gbps SFP+ slots, physical stacking ability, and centralized management. Integrated with strong security and extensive management features, the SG5428XMPP offers a reliable networking solution for SMEs, and ISPs.

IEEE 802.3af/at/bt-compliant Power over Ethernet

8× IEEE 802.3af/at/bt-compliant and 16× IEEE 802.3af/at-compliant PoE ports supply up to 500W total power to 802.3af, 802.3at, and 802.3bt devices.* Set up wireless access points, surveillance cameras, IP phones, and other PoE devices quickly and easily, without the hassle and cost of installing power cabling. Perpetual PoE ensures an uninterrupted power supply to connected devices even during switch reboots. Additionally, the switch retains PoE power settings across reboots, thanks to fast PoE functionality.

High-speed Connectivity and Powerful Stacking

24× gigabit RJ45 ports and 4× 10 Gbps SFP+ slots provide up to 128 Gbps switching capacity per unit. Up to 4 units of physical stacking empower the networking structure with built-in redundancy and performance.

Abundant Layer 3 Capabilities

Comes with abundant Layer 3 routing protocols that support a scalable network. Static Routing, RIP, OSPF, DHCP Server, and DHCP Relay are supported.

Highly Available

ERPS (Ethernet Ring Protection Switching) ensures rapid protection and recovery in ring topologies, which is essential for maintaining network uptime in medium business environments.

Enhanced Security Functions

Defend against a range of network threats with ACL support (IPv4 & IPv6), Dynamic ARP Inspection, IEEE 802.1X, MAB, Port Security, and Secure Shell.

In the Box

  • TP-Link SG5428XMPP Omada 24-Port Gigabit Stackable Lite L3 Managed PoE++ Switch with 4× 10G Slots
  • Power Cord
  • Console Cable
  • Rackmount Kits
  • Rubber Feet
  • Quick Installation Guide
