Illuminator On/Off Control: Zoom Prio; Manual; Smart IR
Illuminator Number: 3 (IR)
Lens
Focal Length: 5.0 mm–80.0 mm Max. Aperture: F1.6
Field of View: H: 53.9°–4.6°; V: 30.3°–2.6°; D: 60°–5.3°, Optical Zoom: 16×
Focus Control: Auto; semi-auto; manual, Close Focus Distance: 0.1 m–2 m (0.33 ft–6.56 ft)
Iris Control: Fixed
DORI Distance Detect: 1,131 m (3,710.63 ft), Observe: 452 m (1,482.94 ft), Recognize: 226 m (741.47 ft), Identify: 113 m (370.73 ft), DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.
PTZ
Pan/Tilt Range: Pan: 0° to 360° endless, Tilt: –15° to +90°, auto flip 180°
Manual Control Speed: Pan: 0.1°/s–80°/s, Tilt: 0.1°/s–80°/s
IVS (Perimeter Protection): Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification
Face Detection: Support face detection; capturing pictures; face enhancement, SMD: Yes
Auto Patrol: It triggers the IVS rule when a target is detected and makes the camera link with the PTZ to rotate to the position of the target and patrol based on its presets
