SPS (Smart Power Stage)
Dr.MOS design features the latest SPS (Smart Power Stage) technology. It’s optimized for monitoring current and temperature of each phase, thus delivering smoother and neater power to the CPU with enhanced performance and OC capability.
1 Power Phase Design
Featuring sturdy components and completely smooth power delivery to the CPU. Plus, it offers unmatched overclocking capabilities and enhanced performance with the lowest temperature for advanced gamers as well.
7W/mK MOSFET Thermal Pads
This thermal pads are much more effective than normal pads. With a 7 watt/mK thermal conductivity it is able to effectively dissipate heat from MOSFET, allowing maximum overclocking potential
10 Layer PCB
The 10 Layer PCB provides stable signal traces and power shapes delivering lower temperature and higher energy efficiency for memory overclocking! Thus, it's able to support the latest memory modules with most extreme memory performance!
PCIe 5.0 + Surface-Mount Tech
Compares to conventional DIP style PCIe slot, the SMT type PCIe slot improves signal flow and maximize stability under high speed, a key breakthrough to fully support the lighting speed of the latest PCIe 5.0 standard.The latest PCI Express 5.0 is capable to perform a breathtaking bandwidth of 128GBps, ready to unleash the full potential of future high end graphic cards.
Reinforced DIMM Slot
Thunderbolt 4/USB4 technology brings speed and versatility to the most advanced USB Type-C, offering a fast and simple level of connection for work or home. It enables lightning-fast data transfer up to 40Gbps and connects external monitors, Thunderbolt, and USB devices with a single Thunderbolt 4 cable.
Fast Charging Technology
Enjoy the superfast charging rate, up to 9V 3A 27W with the next generation PD 3.0!
Nahimic Audio
Whether you are using headphones, a headset, external or internal speakers, via USB, Wi-Fi, analog output or even HDMI, Nahimic Audio offers you the most engaging listening experience, vibrant and rich with details.
POLYCHROME RGB
This motherboard features onboard RGB headers and an addressable RGB header that allow motherboard to be connected to compatible LED devices such as strip, CPU fans, coolers, chassis and so on. Users may also synchronize RGB LED devices across the Polychrome RGB Sync-certified accessories to create their own unique lighting effects
Front USB 3.2 Gen2x2 Type-C
The latest USB 3.2 Gen2x2 Type-C delivers up to 20 Gbps data transfer rate which is 2x as fast as previous generation, providing a blazing fast data transfer interface with reversible USB Type-C design that fits the connector either way.
USB 3.2 Gen2
This motherboard has four onboard Type-A USB 3.2 Gen2 ports built on the rear i/o for supporting next generation USB 3.2 Gen2 devices and to deliver up to 10 Gbps data transfer rates.
Auto Driver Installer
No need to worry about lack of disk drive! Asrock preinstall LAN driver to ensure that you are able to install all drivers needed in an easier way than using SCD.
- step1: Install Auto Driver Installer
- step2: Update drivers needed
- step3: Done!
BIOS Flashback
Get the most convenient BIOS flashing with just a simple click. Users can easily achieve the latest BIOS support with a USB and power supply, No CPU, RAM or other components required.
Flexible Integrated IO Shield
Unlike most so called pre-mounted I/O shield that is only decorated with fancy color schemes. We reserve more tolerance space and allow IO shield is adjustable when installing, thus fitting chassis perfectly without any mechanical issue.
Unique Feature
- ASRock USB 4.0: ASRock USB 4.0 Thunderbolt 4 Type-C Port (40 Gb/s for USB 4.0 protocol; 40Gb/s for Thunderbolt protocol) ASRock USB 3.2 Gen2 ASRock Front Panel Type-C USB 3.2 Gen2x2 Header (20 Gb/s) ASRock USB 3.2 Gen2 Type-A Port (10 Gb/s)
- ASRock Super Alloy: Premium Power Choke, 105A SPS (Smart Power Stage), Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors), I/O Armor, Matte Black PCB, High Density Glass Fabric PCB, 10 Layer PCB, Killer 2.5G LAN, 802.11ax Wi-Fi 6E, Killer DoubleShot Pro, ASRock Auto Driver Installer, ASRock Steel Slot, ASRock Full Coverage M.2 Heatsink, ASRock Hyper M.2 (PCIe Gen4x4, ASRock POST Status Checker PSC, ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
CPU
- Supports 12th Gen Intel Core Processors (LGA1700), Digi Power design, 11 Power Phase design, Supports Intel Hybrid Technology, Supports Inte Turbo Boost Max 3.0 Technology
Memory
- Dual Channel DDR5 Memory Technology2 x DDR5 DIMM SlotsSupports DDR5 non-ECC, un-buffered memory up to 6400+(OC)*Max. capacity of system memory: 64GBSupports Intel Extreme Memory Profile (XMP) 3.015 Gold Contact in DIMM Slots
BIOS
- 256Mb AMI UEFI Legal BIOS with multilingual GUI support, ACPI 6.0 Compliant wake up events, SMBIOS 2.7 Support, CPU CORE/Cache, CPU GT, VCCIN_AUX, VDD_CPU, VDD_IMC, +0.82V PCH, +1.05V, PCH, +1.8V PROC, +1.05V PROC, VDD, VDDQ, VPP Voltage Multi-adjustment
Graphics
- Intel Xe Graphics Architecture (Gen 12)Three graphics output options: HDMI, DisplayPort 1.4 and Intel Thunderbolt 4 portsSupports Triple MonitorSupports Intel Thunderbolt 4 with max. resolution up to 8K (7680x4320) 60HzSupports HDMI 2.1 TMDS Compatible with max. resolution up to 4K x 2K (4096x2160) 60HzSupports DisplayPort 1.4 with DSC (compressed) max. resolution up to 8K (7680x4320) 60Hz / 5K (5120x3200) 120HzSupports HDCP 2.3 with DisplayPort 1.4, HDMI 2.1 TMDS Compatible and Intel Thunderbolt 4 Ports
Audio
- 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec)Premium Blu-ray Audio support, Supports Surge Protection, Pure Power-In, Direct Drive Technology, PCB Isolate Shielding, Impedance Sensing on Rear Out port, Individual PCB Layers for R/L Audio Channel, Gold Audio Jacks, 15μ Gold Audio Connector, Nahimic Audio
LAN
- 2.5 Gigabit LAN 10/100/1000/2500 Mb/s, Killer E3100G, Supports Killer LAN Software, Supports Killer DoubleShot Pro, Supports Wake-On-LAN, Supports Lightning/ESD Protection, Supports Energy Efficient Ethernet 802.3az, Supports PXE
Wireless LAN
- 802.11ax Wi-Fi 6E Module, Supports IEEE 802.11a/b/g/n/ax, Supports Dual-Band 2x2 160MHz with extended 6GHz band support, 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology, Supports Bluetooth + High speed class II, Supports MU-MIMO, Supports Killer LAN Software, Supports Killer DoubleShot Pro
Slots
- PCIe Gen5x16 Slot, Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel CNVi (Integrated WiFi/BT), 15μ Gold Contact in VGA PCIe Slot (PCIE1)
Storage
- 3 x SATA3 6.0 Gb/s Connectors, Hyper M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode, Hyper M.2 Socket (M2_2, Key M), supports type 2280 SATA3 6.0 Gb/s & PCIe Gen4x4 (64 Gb/s) modes
RAID
- Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices, Supports RAID 0, RAID 1 and RAID 5 for M.2 NVMe storage devices
Connector
- Chassis Intrusion and Speaker Header, RGB LED Header, Addressable LED Header, CPU Fan Connector (4-pin), CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control), Chassis Fan Connector (4-pin), 24 pin ATX Power Connector (Hi-Density Power Connector), 8 pin 12V Power Connector (Hi-Density Power Connector), Front Panel Audio Connector (15μ Gold Audio Connector), USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection), USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection), Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s) (Supports ESD Protection)
Rear Panel I/O
- Antenna Ports, HDMI Port, DisplayPort 1.4, Optical SPDIF Out Port, USB 3.2 Gen2 Type-A Ports (10 Gb/s) (Supports ESD Protection), USB 3.2 Gen1 Port (Supports ESD Protection) USB 4.0 Thunderbolt 4 Type-C Port (40 Gb/s for USB 4.0 protocol; 40Gb/s for Thunderbolt protocol) (Supports ESD Protection)* RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED), Clear CMOS Button, BIOS Flashback Button, HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone (Gold Audio Jacks)
Software and UEFI
- Software: ASRock Motherboard Utility (Phantom Gaming Tuning), Killer Control Center, ASRock Polychrome SYNC
- UEFI: ASRock EZ Mode, ASRock Full HD UEFI, ASRock My Favorites in UEFI, ASRock Auto Driver Installer, ASRock Instant Flash,ASRock Internet Flash, ASRock Easy RAID Installer
Support CD
- Drivers, Utilities, AntiVirus Software (Trial Version)
Hardware Monitor
- Fan Tachometer: CPU, CPU/Water Pump, Chassis Fans, Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU/Water Pump Fan, Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis Fans, CASE OPEN detection, Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, VCCSA, VDD_CPU, VCCIN_AUX, +1.05V PCH, +1.05V PROC
