Design Intelligently. Built for heavy workloads with 32GB GDDR6 Memory, 3x DisplayPort 2.1, and AMD Radiance Display Engine -a revolution of light, color and detail with 12-bit HDR.
GPU Specifications
- GPU Architecture: AMD RDNA 3
- Hardware Raytracing: Yes
- Lithography: TSMC 5nm GCD 6nm MCD
- Ray Accelerators: 70
- AI Accelerators: 140
- Stream Processors: 4480
- Compute Units: 70
- Peak Single Precision (FP32 Vector) Performance: 45.2 TFLOPs
- Peak Half Precision (FP16 Vector) Performance: 90.5 TFLOPs
- Peak Half Precision (FP16 Matrix) Performance: 90.4 TFLOPs
- Peak 8-bit Precision (INT8 Matrix) Performance: 90.4 TOPs
- Peak 4-bit Precision (INT4 Matrix) Performance: 181 TOPs
- Transistor Count: 57.7 Billion
- OS Support: Windows 11 - 64-Bit Edition, Windows 10 - 64-Bit Edition, Linux x86 64-Bit
Requirements
- External Power Connectors: 2x8-Pin
- Total Board Power (TBP): 260W
- Minimum PSU Recommendation: 700W
GPU Memory
- Dedicated Memory Size: 32 GB
- Dedicated Memory Type: GDDR6
- AMD Infinity Cache Technology: 64 MB
- Memory Interface: 256-bit
- Peak Memory Bandwidth: 576 GB/s
- Memory ECC Support: Yes
Board
- GPU Form Factor: PCIe Add-in Card
- Bus Type: PCIe 4.0 x16 (3.0 Backward Compatible)
- Cooling: Active
Display Outputs
- DisplayPort: 3x DisplayPort 2.1 and 1x Enhanced Mini DisplayPort 2.1
- Display Configurations: 4x 4096 x 2160 (4K DCI) @ 120Hz with DSC, 2x 6144 x 3456 (6K) 12-bit HDR @ 60Hz Uncompressed, 1x 7680 x 4320 (8K) 12-bit HDR @ 60Hz Uncompressed, 1x 12288 x 6912 (12K) @ 120Hz with DSC
- HDR Support: Yes
- 8K Support: Yes
- 10K Support: Yes
- 12K Support: Yes
Software API Support
- DirectX: 12.0 Ultimate
- OpenGL : 4.6
- OpenCL : 2.1
- Vulkan : 1.3
Miscellaneous
- TPP: 1448
- TPP Density: 2.87
